Airbus A330-300: Specifications, Seat Maps, and Amenities

The Airbus A330-300 is a wide-body, twin-engine airliner that seats approx. 277 passengers in a typical three-class layout and flies up to approx. 11,750 km (6,350 nmi). It measures 63.69 m (208 ft 11 in) in length with a 60.30 m (197 ft 10 in) wingspan, and airlines can fit up to 440 seats in high-density configurations. Below we break down the aircraft’s specifications, seat maps, engine choices, and cabin amenities.

Aircraft engine stands lease

Overview of the Airbus A330-300

The Airbus A330-300 stands as a testament to modern aviation engineering, offering an impressive combination of capacity and range. This twin-engine jet accommodates up to 277 passengers in a typical three-class configuration while covering distances of up to approx. 11,750 km (6,350 nmi). Its versatility and efficiency have made it a preferred choice for airlines worldwide, serving both busy short-haul corridors and long-distance intercontinental routes.

Looking for the shorter, longer-range variant? See our Airbus A330-200 guide.

Engine Stand Trent 700 For Lease

History and Development of the Airbus A330-300

The A330-300’s journey began in the mid-1970s as part of Airbus’s strategic expansion plan. The program’s official launch in June 1987, alongside the A340, marked a significant milestone in aviation history. Through continuous improvements and technological advancements, the aircraft has maintained its competitive edge in the ever-evolving aviation market.

Key Features of the Airbus A330-300

• Low-wing cantilever monoplane design for optimal aerodynamic efficiency
• Two-wheel nose undercarriage and four-wheel bogie main legs for enhanced stability
• Six-screen glass cockpit compatible with other Airbus models
• Increased maximum takeoff weight from 212 to 242 tonnes
• Advanced payload-range performance capabilities

Engine Stand Trent 500/700 APS For Lease

Specifications of the Airbus A330-300

Dimension	Measurement
Length	63.69 meters
Wingspan	60.30 meters
Height	16.99 meters
Cruising Speed	875 km/h
Maximum Altitude	approx. 12,500 meters

Technical Specifications

The A330-300 features a fuselage diameter of 5.64 meters and is powered by two high-bypass turbofan engines, available in three variants: General Electric CF6, Pratt & Whitney PW4000, or Rolls-Royce Trent 700 series. Thrust ratings fall in the approx. 64,000-72,000 lbf class, depending on the engine family and variant.

Performance Metrics

• Maximum range – 11,750 km (6,350 nautical miles)
• Maximum operating Mach number – 0.86
• Passenger capacity – up to 300 (two-class configuration)
• High-density layout capacity – up to 440 passengers
• Maximum takeoff weight – 242 tonnes

Airbus A330-300 Engines: Trent 700, CF6-80E1, and PW4000

Every A330-300 is powered by two engines from one of three families: the Rolls-Royce Trent 700, the General Electric CF6-80E1, or the Pratt & Whitney PW4000-100. The Trent 700 powers the majority of the A330ceo fleet, while the CF6-80E1 and PW4000 remain in widespread service – Delta, for example, flies its A330ceos with PW4000 power. For MRO shops and lessors, the stand has to match the engine: a Trent 700 engine stand carries a different cradle and load rating than a CF6-80E1 engine stand, so a shop visit, an engine swap, or a shipment starts with booking the stand for the right model.

Airbus A330-300 Seat Map and Cabin Layout

The A330-300 offers a spacious and adaptable cabin design that can be customized to meet various airline requirements. Airlines provide interactive seat maps to help passengers make informed seating choices, enhancing the overall travel experience. The cabin’s versatility allows for multiple configuration options, ensuring optimal comfort and efficiency across different route types.

Engine Stand CF6-80E1 For Lease

Seating Capacity and Configuration

The Airbus A330-300 features a versatile seating arrangement that accommodates approx. 277 passengers in a typical three-class configuration. Delta Air Lines seats 293 across three cabins in its layout:

• 34 flat-bed Delta One seats
• 40 Delta Comfort+ seats
• 219 Economy seats

The cabin layout follows strategic configurations to maximize both comfort and efficiency:

Cabin Class	Configuration	Features
Economy	2-4-2	Maximum one seat from aisle access
Business Class	1-2-1	Direct aisle access for all passengers
First Class	2-2-2	Enhanced privacy and comfort

Class Configurations and Comfort

The A330-300’s cabin design prioritizes passenger comfort across all service classes. Using Delta Air Lines’ configuration as a benchmark:

• Delta One (Premium Class) – features flat-bed seats with 80-inch pitch and 21-inch width
• Delta Comfort+ – offers enhanced Economy experience with extra legroom and premium amenities
• Economy Class – provides comfortable seating with competitive pitch and width specifications
• Premium Economy – available on select airlines, bridging Business and Economy with wider seats and increased legroom

Amenities and In-Flight Experience on the Airbus A330-300

The A330-300 delivers a complete travel experience through its state-of-the-art amenities and spacious cabin design. The wide fuselage accommodates generous overhead bin space and comfortable seating arrangements, while airlines can customize interior configurations to match their service standards and route requirements.

Engine Stand PW4000-100 For Lease

In-Flight Entertainment Options

The aircraft’s entertainment system offers extensive content through its Audio and Video On-Demand (AVOD) platform, including:

• Over 4,100 MP3 tracks
• Multiple radio station options
• Diverse selection of movies and TV shows
• Interactive games
• High-definition touchscreen displays at each seat

Additional Comfort Features

The A330-300 enhances passenger comfort with modern amenities including:

• AC power outlets for device charging
• In-flight Wi-Fi connectivity
• Adjustable headrests
• Personal reading lights
• USB charging ports (on select aircraft)
• Customizable seat positions

Airbus A330-300 FAQ

How many passengers does the Airbus A330-300 seat?

The Airbus A330-300 seats approx. 277 passengers in a typical three-class configuration and approx. 300 in two classes. The certified maximum is 440 seats in a high-density layout. Actual capacity varies by airline: Delta Air Lines, for example, operates the type with 293 seats across three cabins.

What is the difference between the Airbus A330-300 and the A330-200?

The A330-300 is the stretched variant: at 63.69 m it is approx. 4.9 m longer than the A330-200 (58.82 m) and carries approx. 30-50 more passengers. The shorter A330-200 trades capacity for range, flying approx. 13,450 km against approx. 11,750 km for the A330-300. Both share the same wing, cockpit, and engine options.

Is the Airbus A330-300 a wide-body aircraft?

Yes. The A330-300 is a wide-body (twin-aisle) aircraft with a fuselage diameter of 5.64 m (18 ft 6 in). Economy cabins are usually arranged 2-4-2 across two aisles, which keeps every passenger within one seat of an aisle. It is the larger of the two passenger variants of the A330ceo family.

Does the Airbus A330-300 have power outlets?

On most modern A330-300s, yes. Many operators, including Delta, install AC power outlets and USB ports at every seat, though availability depends on the airline and cabin class. Check the seat map for your specific flight when booking, as older or high-density configurations may offer outlets only in premium cabins.

What engines power the Airbus A330-300?

The A330-300 is offered with three engine types: the Rolls-Royce Trent 700, General Electric CF6-80E1, and Pratt & Whitney PW4000-100, with thrust ratings in the approx. 64,000-72,000 lbf class depending on variant. The Trent 700 is the most popular choice on the type, powering roughly six out of ten A330ceo aircraft delivered.

How fast does the Airbus A330-300 fly?

The A330-300 cruises at approx. 875 km/h (544 mph, Mach 0.82) with a maximum operating speed of Mach 0.86. Its service ceiling is approx. 12,500 m (41,000 ft). On long-haul sectors this translates to a range of approx. 11,750 km (6,350 nmi) with a typical passenger load.
